Product Name:
BG5333 High temperature Pressure Test Device
AddDate: 2014-05-16
- Summary:
It’s used for testing the dents when wire and cable insulation are in high temperature and under pressure.
Standards:
GB/T2951.21-2008
Technical parameters:
◆ Knife thickness: 0.70±0.01mm
◆ Applied load on the knife: 1N~10N (total: 10 pcs), can be made according to customers’ requirements.
◆ Load acted on the knife edge(from the formula): F= k √2Dδ- δ2
◆ Station: 3
